VeriEye SDK

Iris identification for stand-alone and Web solutions

VeriEye iris identification technology is designed for biometric systems developers and integrators. The technology includes many proprietary solutions that enable robust iris enrollment under various conditions and fast iris matching in 1-to-1 and 1-to-many modes.

Available as a software development kit that allows development of stand-alone and Web-based solutions on Microsoft Windows, Linux, Mac OS X, iOS and Android platforms.

System Requirements

There are specific requirements for each platform which will run VeriEye-based applications.
Click on specific platform to view the corresponding requirements.

Microsoft Windows platform requirements

  • Microsoft Windows Vista / 7 / 8 / 10, 32-bit or 64-bit.
    • Windows XP is no longer supported in this version of the SDK. If your product requires to support Windows XP, you may consider the previous version of the SDK. Please contact us for more information.
  • PC or laptop with x86 (32-bit) or x86-64 (64-bit) compatible processors.
    • 2 GHz or better processor is recommended.
    • SSE2 support is required. Processors that do not support SSE2 cannot run the VeriEye algorithm. Please check if a particular processor model supports SSE2 instruction set.
  • At least 128 MB of free RAM should be available for the application. Additional RAM is required for applications that perform 1-to-many identification, as all biometric templates need to be stored in RAM for matching. For example, 50,000 templates (each containing 2 iris records) require about 223 MB of additional RAM.
  • Free space on hard disk drive (HDD):
    • at least 1 GB required for the development.
    • 100 MB required for VeriEye components deployment.
    • Additional space would be required in these cases:
      • VeriEye does not require the original eye image to be stored for the matching; only the templates need to be stored. However, storing eye irises images on hard drive for the potential future usage is recommended.
      • Usually a database engine runs on a separate computer (back-end server). However, DB engine can be installed on the same computer for standalone applications. In this case HDD space for templates storage must be available. For example, 50,000 templates (each containing 2 iris records) stored using a relational database would require about 223 MB of free HDD space. Also, the database engine itself requires HDD space for running. Please refer to HDD space requirements from the database engine providers.
  • Iris scanner:
    • VeriEye SDK includes support modules for several iris scanners under Microsoft Windows platform.
    • Iris images in BMP, JPG or PNG formats can be processed thus almost any third-party iris capturing hardware can be used with the VeriEye technology if it generates images in the mentioned formats.
    • Integrators may also write plug-ins to support their iris cameras using the plug-in framework provided with the Device Manager from the VeriEye SDK. The integrators should note, that the most accurate iris recognition is achievable only when iris images are captured with near-infrared cameras and appropriate illumination. However, it is still possible to recognize irises with reasonable accuracy, when the irises are captured with regular cameras, using proper illumination and focus, and choosing proper environment. See our testing results for details.
  • Database engine or connection with it. VeriEye templates can be saved into any DB (including files) supporting binary data saving. VeriEye Extended SDK contains the following support modules for Matching Server on Microsoft Windows platform:
    • Microsoft SQL Server;
    • MySQL;
    • Oracle;
    • PostgreSQL;
    • SQLite.
  • Network/LAN connection (TCP/IP) for client/server applications. Also, network connection is required for using Matching server component (included in VeriEye Extended SDK). Communication with Matching server is not encrypted, therefore, if communication must be secured, a dedicated network (not accessible outside the system) or a secured network (such as VPN; VPN must be configured using operating system or third party tools) is recommended.
  • Microsoft .NET framework 3.5 or newer (for .NET components usage).
  • One of following development environments for application development:
    • Microsoft Visual Studio 2012 or newer (for application development under C/C++, C#, Visual Basic .Net)
    • Sun Java 1.6 SDK or later

Android platform requirements

  • A smartphone or tablet that is running Android 4.4 (API level 19) OS or newer.
    • API level 22 is the recommended target for code compilation.
    • If you have a custom Android-based device or development board, contact us to find out if it is supported.
  • ARM-based 1.5 GHz processor recommended for iris processing in the specified time. Slower processors may be also used, but the iris processing will take longer time.
  • At least 20 MB of free RAM should be available for the application. Additional RAM is required for applications that perform 1-to-many identification, as all biometric templates need to be stored in RAM for matching. For example, 1,000 templates (each containing 1 iris record) require about 2.5 MB of additional RAM.
  • Free storage space (built-in flash or external memory card):
    • 30 MB required for embedded iris components deployment for each separate application.
    • Additional space would be required if an application needs to store original eye images. VeriEye does not require the original eye iris image to be stored for the matching; only the templates need to be stored.
  • Iris scanner:
    • VeriEye SDK includes support modules for several iris scanners under Android platform.
    • Iris images in BMP, JPG or PNG formats can be processed thus almost any third-party iris capturing hardware can be used with the VeriEye technology if it generates images in the mentioned formats.
    • Integrators may also write plug-ins to support their iris cameras using the plug-in framework provided with the Device Manager from the VeriEye SDK. The integrators should note, that the most accurate iris recognition is achievable only when iris images are captured with near-infrared cameras and appropriate illumination. However, it is still possible to recognize irises with reasonable accuracy, when the irises are captured with cameras, which are built in smartphones or tablets, using proper illumination and focus, and choosing proper environment. See our testing results for details.
  • Network/LAN connection (TCP/IP) for client/server applications. Also, network connection is required for using Matching server component (included in VeriEye Extended SDK). Communication with Matching server is not encrypted, therefore, if communication must be secured, a dedicated network (not accessible outside the system) or a secured network (such as VPN; VPN must be configured using operating system or third party tools) is recommended.
  • PC-side development environment requirements:
    • Java SE JDK 6 (or higher)
    • Eclipse Indigo (3.7) IDE
    • Android development environment (at least API level 19 required)
    • One of the following build automation systems:
    • Internet connection for activating VeriEye component licenses

iOS platform requirements

  • One of the following devices, running iOS 8.0 or newer:
    • iPhone 5 or newer iPhone.
    • iPad 2 or newer iPad, including iPad Mini and iPad Air models.
    • iPod Touch 6th Generation or newer iPod.
  • At least 20 MB of free RAM should be available for the application. Additional RAM is required for applications that perform 1-to-many identification, as all biometric templates need to be stored in RAM for matching. For example, 1,000 templates (each containing 1 iris record) require about 2.5 MB of additional RAM.
  • Free storage space (built-in flash or external memory card):
    • 30 MB required for embedded iris components deployment for each separate application.
    • Additional space would be required if an application needs to store original iris images. VeriEye does not require the original eye iris image to be stored for the matching; only the templates need to be stored.
  • Iris scanner:
    • At the moment iris scanner support on iOS platform should be implemented by integrators. The integrators should note, that the most accurate iris recognition is achievable only when iris images are captured with near-infrared cameras and appropriate illumination. However, it is still possible to recognize irises with reasonable accuracy, when the irises are captured with cameras, which are built in smartphones or tablets, using proper illumination and focus, and choosing proper environment. See our testing results for details.
    • Iris images in BMP, JPG or PNG formats can be processed thus almost any third-party iris capturing hardware can be used with the VeriEye technology if it generates images in the mentioned formats.
  • Network/LAN connection (TCP/IP) for client/server applications. Also, network connection is required for using Matching server component (included in VeriEye Extended SDK). Communication with Matching server is not encrypted, therefore, if communication must be secured, a dedicated network (not accessible outside the system) or a secured network (such as VPN; VPN must be configured using operating system or third party tools) is recommended.
  • Development environment requirements:
    • a Mac running Mac OS X 10.10.x or newer.
    • Xcode 6.4 or newer.

Mac OS X platform requirements

  • A Mac running Mac OS X 10.7.x or newer. 2 GHz or better processor is recommended.
  • At least 128 MB of free RAM should be available for the application. Additional RAM is required for applications that perform 1-to-many identification, as all biometric templates need to be stored in RAM for matching. For example, 10,000 templates (each with 1 iris record) require about 25 MB of additional RAM.
  • Free space on hard disk drive (HDD):
    • at least 1 GB required for the development.
    • 100 MB required for VeriEye components deployment.
    • Additional space would be required in these cases:
      • VeriEye does not require the original eye iris image to be stored for the matching; only the templates need to be stored. However, storing iris images on hard drive for the potential future usage is recommended.
      • Usually a database engine runs on a separate computer (back-end server). However, DB engine can be installed on the same computer for standalone applications. In this case HDD space for templates storage must be available. For example, 10,000 templates (each with 1 iris record) stored using a relational database would require about 25 MB of free HDD space. Also, the database engine itself requires HDD space for running. Please refer to HDD space requirements from the database engine providers.
  • Iris scanner:
    • At the moment iris scanner support on Mac OS X platform should be implemented by integrators. The integrators should note, that the most accurate iris recognition is achievable only when iris images are captured with near-infrared cameras and appropriate illumination. However, it is still possible to recognize irises with reasonable accuracy, when the irises are captured with regular cameras, using proper illumination and focus, and choosing proper environment. See our testing results for details.
    • Iris images in BMP, JPG or PNG formats can be processed thus almost any third-party iris capturing hardware can be used with the VeriEye technology if it generates images in the mentioned formats.
  • Database engine or connection with it. VeriEye templates can be saved into any DB (including files) supporting binary data saving. VeriEye Extended SDK contains SQLite support modules for Matching Server on Mac OS X platform.
  • Network/LAN connection (TCP/IP) for client/server applications. Also, network connection is required for using Matching server component (included in VeriEye Extended SDK). Communication with Matching server is not encrypted, therefore, if communication must be secured, a dedicated network (not accessible outside the system) or a secured network (such as VPN; VPN must be configured using operating system or third party tools) is recommended.
  • Specific requirements for application development:
    • XCode 4.3 or newer
    • wxWidgets 3.0.0 or newer libs and dev packages (to build and run SDK samples and applications based on them)
    • Qt 4.8 or newer libs, dev and qmake packages (to build and run SDK samples and applications based on them)
    • GNU Make 3.81 or newer (to build samples and tutorials development)
    • Sun Java 1.6 SDK or later

Linux x86 / x86-64 platform requirements

  • Linux 2.6 or newer kernel (32-bit or 64-bit) is required. Linux 3.0 kernel or newer is recommended.
  • PC or laptop with x86 (32-bit) or x86-64 (64-bit) compatible processors.
    • 2 GHz or better processor is recommended.
    • SSE2 support is required. Processors that do not support SSE2 cannot run the VeriLook algorithm. Please check if a particular processor model supports SSE2 instruction set.
  • At least 128 MB of free RAM should be available for the application. Additional RAM is required for applications that perform 1-to-many identification, as all biometric templates need to be stored in RAM for matching. For example, 10,000 templates (each with 1 iris record) require about 25 MB of additional RAM.
  • Free space on hard disk drive (HDD):
    • at least 1 GB required for the development.
    • 100 MB required for VeriEye components deployment.
    • Additional space would be required in these cases:
      • VeriEye does not require the original eye iris image to be stored for the matching; only the templates need to be stored. However, storing iris images on hard drive for the potential future usage is recommended.
      • Usually a database engine runs on a separate computer (back-end server). However, DB engine can be installed on the same computer for standalone applications. In this case HDD space for templates storage must be available. For example, 10,000 templates (each with 1 iris record inside) stored using a relational database would require about 40 MB of free HDD space. Also, the database engine itself requires HDD space for running. Please refer to HDD space requirements from the database engine providers.
  • Iris scanner:
    • VeriEye SDK includes support modules for several iris scanners under Linux x86 platform.
    • Iris images in BMP, JPG or PNG formats can be processed thus almost any third-party iris capturing hardware can be used with the VeriEye technology if it generates images in the mentioned formats.
    • Integrators may also write plug-ins to support their iris cameras using the plug-in framework provided with the Device Manager from the VeriEye SDK. The integrators should note, that the most accurate iris recognition is achievable only when iris images are captured with near-infrared cameras and appropriate illumination. However, it is still possible to recognize irises with reasonable accuracy, when the irises are captured with regular cameras, using proper illumination and focus, and choosing proper environment. See our testing results for details.
  • glibc 2.11.3 library or newer
  • Database engine or connection with it. VeriEye templates can be saved into any DB (including files) supporting binary data saving. VeriEye Extended SDK contains the following support modules for Matching Server on Linux platform:
    • MySQL;
    • Oracle;
    • PostgreSQL;
    • SQLite.
  • Network/LAN connection (TCP/IP) for client/server applications. Also, network connection is required for using Matching server component (included in VeriEye Extended SDK). Communication with Matching server is not encrypted, therefore, if communication must be secured, a dedicated network (not accessible outside the system) or a secured network (such as VPN; VPN must be configured using operating system or third party tools) is recommended.
  • Specific requirements for application development:
    • wxWidgets 3.0.0 or newer libs and dev packages (to build and run SDK samples and applications based on them)
    • Qt 4.8 or newer libs, dev and qmake packages (to build and run SDK samples and applications based on them)
    • GCC-4.4.x or newer
    • GNU Make 3.81 or newer
    • Sun Java 1.6 SDK or later
    • pkg-config-0.21 or newer (optional; only for Matching Server database support modules compilation)

ARM Linux platform requirements

We recommend to contact us and report the specifications of a target device to find out if it will be suitable for running VeriEye-based applications.

There is a list of common requirements for ARM Linux platform:

  • A device with ARM-based processor, running Linux 3.2 kernel or newer.
  • ARM-based 1.5 GHz processor recommended for iris processing in the specified time.
    • ARMHF architecture (EABI 32-bit hard-float ARMv7) is required.
    • Lower clock-rate processors may be also used, but the iris processing will take longer time.
  • At least 128 MB of free RAM should be available for the application. Additional RAM is required for applications that perform 1-to-many identification, as all biometric templates need to be stored in RAM for matching. For example, 1,000 templates (each containing 1 iris record) require about 2.5 MB of additional RAM.
  • Free storage space (built-in flash or external memory card):
    • 100 MB required for VeriEye components deployment.
    • Additional space would be required in these cases:
      • An application needs to store original eye / iris images. Note that VeriEye does not require the original images to be stored for the matching; only the templates need to be stored.
      • Usually a database engine runs on a separate computer (back-end server). However, a DB engine can be installed on the same device for standalone applications. For example, 1,000 templates (each with 1 iris record) stored using a relational database would require about 2.5 MB of free storage space.
        PostgreSQL, MySQL and SQLite are supported on ARM-Linux. Please refer to hardware requirements from the corresponding database engine providers.
  • Iris scanner:
    • At the moment iris scanner support on ARM Linux platform should be implemented by integrators. The integrators should note, that the most accurate iris recognition is achievable only when iris images are captured with near-infrared cameras and appropriate illumination. However, it is still possible to recognize irises with reasonable accuracy, when the irises are captured with regular cameras, using proper illumination and focus, and choosing proper environment. See our testing results for details.
    • Iris images in BMP, JPG or PNG formats can be processed thus almost any third-party iris capturing hardware can be used with the VeriEye technology if it generates images in the mentioned formats.
  • glibc 2.13 or newer.
  • libstdc++-v3 4.7.2 or newer.
  • Network/LAN connection (TCP/IP) for client/server applications. Also, network connection is required for using Matching server component (included in VeriEye Extended SDK). Communication with Matching server is not encrypted, therefore, if communication must be secured, a dedicated network (not accessible outside the system) or a secured network (such as VPN; VPN must be configured using operating system or third party tools) is recommended.
  • Development environment specific requirements:
    • GCC-4.4.x or newer
    • GNU Make 3.81 or newer
    • JDK 1.6 or later
